| RoHS |
No RoHS Information
|
| EDA/CAD Models |
TS5A23157DGSR PCB Footprint and Symbol |
| Warranty |
Up to 1 year [Limited-Warranty]* |
| Brand |
Texas Instruments |
| Product Line |
Semiconductors |
| Subcategory |
Analog Switches, Multiplexers, Demultiplexers |
| Series |
- |
| Switch Circuit |
SPDT |
| Multiplexer/Demultiplexer Circuit |
2:1 |
| Number of Circuits |
2 |
| On-State Resistance (Max) |
10Ohm |
| Channel-to-Channel Matching (ΔRon) |
150mOhm |
| Voltage - Supply, Single (V+) |
1.65V ~ 5.5V |
| Voltage - Supply, Dual (V±) |
- |
| Switch Time (Ton, Toff) (Max) |
5.7ns, 3.8ns |
| -3db Bandwidth |
220MHz |
| Charge Injection |
7pC |
| Channel Capacitance (CS(off), CD(off)) |
5.5pF |
| Current - Leakage (IS(off)) (Max) |
1µA |
| Crosstalk |
-66dB @ 10MHz |
| Operating Temperature |
-40°C ~ 85°C (TA) |
| Package / Case |
10-TFSOP, 10-MSOP (0.118", 3.00mm Width) |
| Supplier Device Package |
10-VSSOP |
