| RoHS |
No RoHS Information |
| EDA/CAD Models |
TDE1898CFP PCB Footprint and Symbol |
| Warranty |
Up to 1 year [Limited-Warranty]* |
| Brand |
STMicroelectronics |
| Product Line |
Semiconductors |
| Subcategory |
Power Distribution Switches, Load Drivers |
| Series |
- |
| Switch Type |
General Purpose |
| Number of Outputs |
1 |
| Ratio - Input:Output |
1:1 |
| Output Configuration |
High Side |
| Output Type |
N-Channel |
| Interface |
On/Off |
| Voltage - Load |
18V ~ 35V |
| Voltage - Supply (Vcc/Vdd) |
Not Required |
| Current - Output (Max) |
500mA |
| Rds On (Typ) |
- |
| Input Type |
Differential |
| Features |
- |
| Fault Protection |
Current Limiting (Fixed), Open Load Detect, Over Temperature, UVLO |
| Operating Temperature |
-25°C ~ 85°C (TA) |
| Package / Case |
20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package |
20-SO |
