NCV5701ADR2G
| Part Number | NCV5701ADR2G |
| Category | Power Management ICs |
| Description | HIGH CURRENT IGBT GATE DR |
| Brand | ON Semiconductor |
NCV5701ADR2G Specifications
| RoHS | No RoHS Information |
| EDA/CAD Models | NCV5701ADR2G PCB Footprint and Symbol |
| Product Line | Semiconductors |
| Subcategory | Gate Drivers |
| Series | - |
| Driven Configuration | High-Side or Low-Side |
| Channel Type | Single |
| Number of Drivers | 1 |
| Gate Type | IGBT |
| Voltage - Supply | 20V |
| Logic Voltage - VIL, VIH | 0.75V, 4.3V |
| Current - Peak Output (Source, Sink) | 20mA, 15mA |
| Input Type | Inverting |
| High Side Voltage - Max (Bootstrap) | - |
| Rise / Fall Time (Typ) | 9.2ns, 7.9ns |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| part_number_key_clear | NCV5701ADR2G |
Quick Inquiry
| In Stock | 455 - More on Order |
| Quote Limit | No Limit |
| Lead-Time | To be Confirmed |
| Minimum | 1 |
