MM75G3T65B
| Part Number | MM75G3T65B |
| Description | |
| Brand | MACMIC |
| Category | Transistors |
MM75G3T65B Specifications
| Subcategory | IGBTs - Single |
| Product Line | Semiconductors |
| Collector Current (25°C) | 115A |
| Collector-Emitter Voltage (VCES) | 650V |
| Continuous Collector Current | 75A (Tc = 100°C) |
| Device Type | IGBT Power Transistor |
| Gate-Emitter Voltage | ±20V |
| Integrated Diode | Yes (Fast Recovery) |
| Maximum Junction Temperature | 175°C |
| Model | MM75G3T65B |
| Package | TO-247 |
| Pulsed Collector Current | 225A |
| Technology | Trench Field Stop IGBT |
| Typical VCE(sat) | Approximately 1.45V @ 25°C |
Quick Inquiry
| In Stock | 682 - More on Order |
| Quote Limit | No Limit |
| Lead-Time | To be Confirmed |
| Minimum | 1 |
Please fill out the form below. We will contact you as soon as possible.
Add to cart
You can first add the current product to the shopping cart and then make a one-time inquiry.
