| RoHS |
No RoHS Information
|
| EDA/CAD Models |
FODM8071R2 PCB Footprint and Symbol |
| Warranty |
Up to 1 year [Limited-Warranty]* |
| Brand |
ON Semiconductor |
| Product Line |
Semiconductors |
| Subcategory |
Optoisolators - Logic Output |
| Series |
- |
| Number of Channels |
1 |
| Inputs - Side 1/Side 2 |
1/0 |
| Voltage - Isolation |
3750Vrms |
| Common Mode Transient Immunity (Min) |
20kV/µs |
| Input Type |
DC |
| Output Type |
Push-Pull, Totem Pole |
| Current - Output / Channel |
10mA |
| Data Rate |
20Mbps |
| Propagation Delay tpLH / tpHL (Max) |
55ns, 55ns |
| Rise / Fall Time (Typ) |
5.8ns, 5.3ns |
| Voltage - Forward (Vf) (Typ) |
1.35V |
| Current - DC Forward (If) (Max) |
20mA |
| Voltage - Supply |
3V ~ 5.5V |
| Operating Temperature |
-40°C ~ 110°C |
| Mounting Type |
Surface Mount |
| Package / Case |
6-SOIC (0.173", 4.40mm Width), 5 Leads |
| Supplier Device Package |
5-Mini-Flat |
