| RoHS |
No RoHS Information
|
| EDA/CAD Models |
ACPL-W314-500E PCB Footprint and Symbol |
| Warranty |
Up to 1 year [Limited-Warranty]* |
| Brand |
Broadcom |
| Product Line |
Semiconductors |
| Subcategory |
Isolators - Gate Drivers |
| Series |
- |
| Technology |
Optical Coupling |
| Number of Channels |
1 |
| Voltage - Isolation |
5000Vrms |
| Common Mode Transient Immunity (Min) |
25kV/µs |
| Propagation Delay tpLH / tpHL (Max) |
700ns, 700ns |
| Pulse Width Distortion (Max) |
- |
| Rise / Fall Time (Typ) |
50ns, 50ns |
| Current - Output High, Low |
400mA, 400mA |
| Current - Peak Output |
600mA |
| Voltage - Forward (Vf) (Typ) |
1.5V |
| Current - DC Forward (If) (Max) |
25mA |
| Voltage - Output Supply |
10V ~ 30V |
| Operating Temperature |
-40°C ~ 100°C |
| Mounting Type |
Surface Mount |
| Package / Case |
6-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package |
6-SO |
| Approvals |
CSA, UR |
